VENTILATOR 12V 120x120x25mm 157.9m/h 3.4W

Cod produs - SKU 5225
PN: 10994
In stoc
59,90 LEI
49,50 LEI (fara TVA)
Costurile de livrare nu sunt incluse
Stoc 3
Toate preturile sunt exprimate in RON si includ TVA

Transport gratuit pentru comenzi de minim 500 RON (TVA inclus).
Taxa procesare 20 RON (TVA inclus) pentru comenzi sub 50 RON (TVA inclus).
Pentru oferte si termene de livrare va rugam sa ne scrieti la adresa contact@conexelectronic.ro.
  • Descriere
  • Detalii
  • Fisiere asociate
  • Ce spun clientii

Descriere

Fan 12V 120x25 B 157,9m³/h 40,5dBA

Design
• Motor: DC Brushless Motor Design
• Nr. of Motor Poles: 4
• Frames, Impeller: Filled Thermoplastic PBT (UL94V-0)
• Bearing System
- ME_V_: Vapo
- EE_B_: Two Ball Bearing
• Lead Wire: AWG24, UL1007, Stripped, Tinned

Technical Specifications
• Rated Voltage
- 12V: 12V DC
- 24V: 24V DC
- 48V: 48V DC
• Operating Voltage
- 12V: 6...13,8V DC
- 24V: 6...27,6V DC
- 48V: 30...56V DC
• Starting Voltage
- 12V: 6V DC
- 24V: 10V DC
- 48V: 30V DC
• Dielectric Strength: 500V AC for 1 Min.
• Insulation Class: A
• Insulation Resistance at 500V DC: 10MOhm
• Storage Temperature: -40...+70°C
• Operating Temperature: -10...+70°C

• U rated: 12V
• Airflow: 157.97m³/h
• Noise: 40.5dBA
• I: 0.300A
• Rated Power and Current Tolerance, ±15%: 3.6W
• Speed: 2700RPM

Detalii

SKU
5225
Categorii
Ventilatoare
Greutate
0.16 kg
Viteza rotatie
2700 rot./min
Tip ventilator
Axial
Terminale
Cablu 2 fire
Tensiune alimentare
12V DC
Sistem lagare
Cu bila
Nivel zgomot [dBA]
40.5 dBA
Material elice
Termoplastic
Material caseta
Termoplastic
Dimensiuni (L x l x h)(mm)
120 x 120 x 25 mm
