220 MF/25 V 105 grd 120 KHz LOW ESR

Cod produs - SKU 9034
PN: 13820
In stoc
2,50 LEI
2,07 LEI (fara TVA)
Costurile de livrare nu sunt incluse
Toate preturile sunt exprimate in RON si includ TVA

Transport gratuit pentru comenzi de minim 500 RON (TVA inclus).
Taxa procesare 20 RON (TVA inclus) pentru comenzi sub 50 RON (TVA inclus).
Pentru oferte si termene de livrare va rugam sa ne scrieti la adresa contact@conexelectronic.ro.
  • Descriere
  • Detalii
  • Fisiere asociate
  • Ce spun clientii

Descriere

El-Capacitor 220uF 25V 8x16mm P3,5

Features
• Aluminium encased insulation
• Radial leads
• High temperature range (up to 105°C)
• Low impedance and low RESR
• High load life
• For high frequency
• Suitable for switching power supplies

Technical Specifications
• Voltage Rating: 25V DC
• Rated Voltage: 32V
• Surge Voltage, tan d (120Hz, 25°C): 9,0
• Capacitance Tolerance: ±20%
• Temperature Range: -55...+105°C
• Leakage Current, Max.: 0,01xCxUN or 4µA
• Load Life: 5000h (2000h at 8min.)

• Rated Capacitance: 220µF
• Max. Impedance (20°C, 120 KHz): 0.156 Ohm
• Ripple Current (105°C, 100kHz): 550mA
• D: 8.0mm
• L: 16mm
• Pitch: 3.5mm
• d: 0.5mm
