8.2 K/5 W

Cod produs - SKU 8145
PN: 13215
In stoc
2,50 LEI
2,07 LEI (fara TVA)
Costurile de livrare nu sunt incluse
Toate preturile sunt exprimate in RON si includ TVA

Transport gratuit pentru comenzi de minim 500 RON (TVA inclus).
Taxa procesare 20 RON (TVA inclus) pentru comenzi sub 50 RON (TVA inclus).
Pentru oferte si termene de livrare va rugam sa ne scrieti la adresa contact@conexelectronic.ro.
  • Descriere
  • Detalii
  • Fisiere asociate
  • Ce spun clientii

Descriere

Resistor 5W 10% 8,2K
Features
• Wound on a glass fiber core with special direct terminals, temperature resistant
• Wound resistor embedded in a cement sealed ceramic tube

Technical Specifications
• Resistance Value: Row E12, Reduced
• Resistance Tolerance: ±10%
• Power Rating (70°C): 5W
• Operating Voltage, Max.: (P70xR)
• Thermal Resistance: 50K/W
• Insulation Resistance: >10000 MOhm
• Insulation Voltage: 2000Vrms
• Temperature Range: -55...+350°C
• Climatic Category: 55/200/21
• Terminal Tensile Strength: 50N
• Solderability (Solderglobule Test, IEC68-2-20T): 2,5s
• Derating: Linear 70°C to 350°C (0W)
