BOBINA 2.2uH 630mA miniatura

Cod produs - SKU 11812
PN: EC24-2R2K
Stoc epuizat
1,00 LEI
0,83 LEI (fara TVA)
Costurile de livrare nu sunt incluse
Acest produs nu este disponibil momentan. Vrei sa te anuntam cand revine?
Toate preturile sunt exprimate in RON si includ TVA

Transport gratuit pentru comenzi de minim 500 RON (TVA inclus).
Taxa procesare 20 RON (TVA inclus) pentru comenzi sub 50 RON (TVA inclus).
Pentru oferte si termene de livrare va rugam sa ne scrieti la adresa contact@conexelectronic.ro.
  • Descriere
  • Detalii
  • Ce spun clientii

Descriere

Inductor Axial 2,2uH 630mA 3x10mm

Application
Decoupling and interference suppression of circuits within the HF/NF range

Features
• Small miniature fixed inductors
• High resonant frequency and quality class due to the special features of the ferrite core
• The epoxy resin lacquer finish provides a very good protection against humidity which increases the operating life
• Heatproof design for safe application in switching circuits

Technical Specifications
• Temperature Range: -20...+100°C
• Dielectric Strength: 250Vrms
• Inductance (DL): ±10%

• Inductance: 2.2µH
• Quality Class: 40
• Testing Frequency of L and Q: 7.96MHz
• Resonance Frequency, Min.: 80.0MHz
• DC Resistance, Max.: 0.25Ohm
• Rated DC Current: 630mA
