6.8 KOHM/9W

Cod produs - SKU 20232
PN: 6331
In stoc
7,50 LEI
6,20 LEI (fara TVA)
Costurile de livrare nu sunt incluse
Toate preturile sunt exprimate in RON si includ TVA

Transport gratuit pentru comenzi de minim 500 RON (TVA inclus).
Taxa procesare 20 RON (TVA inclus) pentru comenzi sub 50 RON (TVA inclus).
Pentru oferte si termene de livrare va rugam sa ne scrieti la adresa contact@conexelectronic.ro.
  • Descriere
  • Detalii
  • Fisiere asociate
  • Ce spun clientii

Descriere

WW Power Resistor 9W 10% 6K8

Features
• Wound on a glass fiber core with special direct terminals, temperature resistant
• Wound resistor embedded in a cement sealed ceramic tube

Technical Specifications
• Resistance Tolerance: ±10%
• Power Rating (70°C): 9W
• Operating Voltage, Max.: (PxR)1/2
• Thermal Resistance: 30K/W
• Insulation Resistance, Min.: 104 MOhm
• Insulation Voltage (1Min.): 2000Veff
Temperature Coefficient
– 0R11...0R68: +400 ±50ppm/K
– 0R75...910R: 0 ±40ppm/K
– 1K0...33K: 0 ±10ppm/K
• Temperature Range: -55...+350°C
• Climatic Category: 55/200/21
• Failure Rate (Value Dependent): Approx. 100x10-9 /h
• Terminal Tensile Strength: 50N
• Solderability:1) 2,5s
• Derating: Linear 70°C to 350°C (0W)

(1) Solderglobule Test, IEC 60068-2-20-T
