RELEU 24 V/8 A 1200 R SPDT ORIZONTAL

Cod produs - SKU 18116
PN: KRE24L
Stoc epuizat

Releu SPDT; Ubobina: 24VDC, 8A/250VAC, 8A/24VDC

22,50 LEI
18,60 LEI (fara TVA)
Costurile de livrare nu sunt incluse
Acest produs nu este disponibil momentan. Vrei sa te anuntam cand revine?
Toate preturile sunt exprimate in RON si includ TVA

Transport gratuit pentru comenzi de minim 500 RON (TVA inclus).
Taxa procesare 20 RON (TVA inclus) pentru comenzi sub 50 RON (TVA inclus).
Pentru oferte si termene de livrare va rugam sa ne scrieti la adresa contact@conexelectronic.ro.
  • Descriere
  • Detalii
  • Fisiere asociate
  • Ce spun clientii

Descriere

Relay SPDT 8A 24V 1200R Horizontal

Features
• 4kV coil/contact
• Version with bifurcated contacts
• Wash tight RTIII

Technical Specifications
• Contact: SPDT (Single Contact)
• Contact Material: AgCdO
• Rated Current: 8A
• Max. Switching Current: 15A
• Max. Switching Voltage: 400V AC
• Max. Switching Power: 2000VA
• Creepage/Clearance: >=4/4mm
• Operate/Release Time: 7/3ms
• Testing Voltage
– Coil/Contact: 4000Vrms
– Opening Contact: 1000Vrms
• Lifetime
– Mechanical: 20x1000000 Operations
– Operating Temperature: -40...+70°C
• Weight Approx.: 14g

• Rated Voltage: 24V DC
• Operate Voltage: 16V
• Release Voltage: 2.4V
• Rated Power: 480mW
• Coil Resistance: 1200Ohm
All Specifications Measured at 23°C

Denumire / cod producator: TE Connectivity 2-1393215-5

Detalii

SKU
18116
Categorii
Relee
Tip releu
miniatura
Tip contacte
SPDT
Tensiune nominala bobina
24V DC
Tensiune max. comutata
400V AC
Temperatura °C
- 40...70
Sarcina admisibila [DC]
8A / 24V DC
Sarcina admisibila [AC]
8A / 250V AC
Montare
PCB
Curent max. contacte [A]
15
Descriere scurta

Releu SPDT; Ubobina: 24VDC, 8A/250VAC, 8A/24VDC
